Distillation analyzers play a critical role in fuel oil blending process control. The following elaborates on their applications:

1. Real-Time Monitoring of Key Parameters and Quality Control

By simulating the heating and fractional distillation process, distillation analyzers measure the initial boiling point, final boiling point, and volume recovery rates at various temperature segments of fuel oil in real time, generating a complete distillation curve. In the blending process, this data accurately reflects differences in evaporation characteristics among component oils (such as light naphtha, diesel, coal tar, etc.), ensuring that the boiling range of the mixed product meets target standards (e.g., a dry point ≤205°C for automotive gasoline). For example:

· Volatility regulation: By monitoring the proportion of low-boiling components (like light hydrocarbons in gasoline blending), it prevents combustion instability or safety hazards caused by excessive volatility.

· Balancing heavy components: For high-boiling substances in fuel oil (such as coal tar), the analyzer can identify their carbon residue and final boiling point, preventing increased viscosity or coking tendency after blending.

2. Dynamic Optimization of Process Parameters

Based on immediate feedback from distillation data, the analyzer guides dynamic adjustments in the blending process:

· Optimizing mixing ratios: According to the distillation characteristics of each component oil (e.g., narrow boiling range of naphtha vs. wide boiling range of crude diesel), it calculates the optimal ratio to achieve a balance in comprehensive properties such as octane number and flash point.

· Heating and condensation control: Through high-precision temperature sensors (±0.1°C) and intelligent temperature control systems, it regulates the heating rate and condensation efficiency of the blending tank, ensuring uniform dispersion of components and reducing the risk of thermal cracking.

3. Ensuring Standardized Compliance

Modern distillation analyzers strictly adhere to international standards such as ASTM D86, providing authoritative data support for the blending process:

· Quality inspection verification: Rapidly completes distillation testing before finished products leave the factory, generating visual reports to meet environmental regulations (indirect correlation between sulfur content and distillation distribution) and industry specifications.

· Anomaly warning: By comparing historical data with preset thresholds, it promptly detects distillation deviations caused by raw material contamination or equipment failure, reducing the risk of batch scrapping.

4. Advantages of Intelligence and Integration

The new generation of distillation analyzers adopts modular design and Internet of Things (IoT) technology, further enhancing the efficiency of process control:

· Full-process automation: From sample introduction to cloud data upload, the entire process requires no manual intervention, supporting standalone operation or centralized management of up to 32 devices connected in parallel, catering to large-scale continuous production needs.

· AI-assisted decision-making: Built-in algorithms can fit distillation curves and predict the physical and chemical properties of blended products, achieving closed-loop control when integrated with Laboratory Information Management Systems (LIMS).

5. Typical Application Scenarios

· Aviation fuel blending: Precisely controls the freezing point and calorific value stability of jet fuel to ensure flight safety at high altitudes.

· Marine fuel oil: Monitors the viscosity and pour point after blending residual oil with light diesel, meeting the requirements for low-temperature starting of ship engines.

· Special solvent production: Expands the detection range through vacuum distillation accessories for chemicals like methanol and benzene, ensuring consistency in high-purity products.

In summary, distillation analyzers have become indispensable core equipment in fuel oil blending processes due to their precise detection capabilities, intelligent operating procedures, and standardized data output. They not only address the efficiency bottlenecks of traditional manual testing but also promote the upgrading of blending processes toward refinement and greening through real-time data analysis.
